Hyperloop Station by RB Systems

RB Systems proposes an exceptional Hyperloop Station and passenger pod.

RB Systems unveiled this impressive futuristic design vision for a Hyperloop station.

Hyperloop Station by RB Systems (20)



From the Architects website:



For the Hyperloop transportation system proposed by Elon Musk earlier in 2015, Rustem Baishev of RB Systems presents an integrated design vision both for a station and a passenger pod. The station’s design is as of now speculative and is not tied to a specific location, due to yet uncertain public intent in commissioning such building; nonetheless – with a firm promise of such intent to arise in the foreseeable future – there is a strong sense in exploring its potential layouts.

Hyperloop Station by RB Systems (19)



The expected pod’s travel speed of nearly 1200 km/h is a well-known item for discussion leading to many engineering challenges in the tube’s design. But the greater issue for designing a Hyperloop station’s layout is that proposed rate of departures / arrivals is too very rapid in its own respect, estimated to be at 1 pod per minute. Meaning that complete pod’s handling – to include many various operations – must be performed within such an extremely short amount of time.

Hyperloop Station by RB Systems (18)





One of the key-features of the design is the method proposed for separation of the vehicular flow through the station – an answer on how to connect a single exit from the tube with at least 20 platforms. An initial analysis had revealed that mechanical applications, especially exposed ones, involving rotary systems, elevating systems – might likely be subject to jams affecting the scheduled queue operations in a domino effect, and may also require a constant surveillance and a frequent maintenance.

Hyperloop Station by RB Systems (17)

Hyperloop Station by RB Systems (16)

Hyperloop Station by RB Systems (15)



Hyperloop Station by RB Systems (14)

via archdaily

source RB Systems
